| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 55GHz | |
| ● | Pass Band Frequency | 45 ~ 65GHz | |
| ● | Pass Band Insertion Loss | ≤1.5dB @ 45 ~ 64GHz | ≤1.8dB @ 64 ~ 65GHz |
| ● | Pass Band Ripple | ≤0.8dB @ 45 ~ 64GHz | ≤1.1dB @ 64 ~ 65GHz |
| ● | Pass Band Return Loss | ≥11dB (Typical: 13.5dB) | |
| ● | Stop Band Rejection | ≥80dB @ DC ~ 42.5GHz | ≥10dB @ 66.5 ~ 69.7GHz |
| ≥30dB @ 42.5 ~ 44GHz | |||
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | 1.85mm(V)-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
