Technical Data Sheet
●	Stop Band Frequency	2500 ~ 2570MHz
●	Stop Band Attenuation	≥60dB
●	Pass Band Frequency	DC ~ 2475MHz , 2595 ~ 6500MHz
●	Pass Band Insertion Loss	≤2.0dB (at the corner: 3.0dB Max.)
●	Pass Band VSWR	≤1.5:1
●	Impedance	50 Ohms
●	Power	50W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-20℃ ~ +60℃
Test Curve
