Technical Data Sheet
●	Stop Band Frequency	3300 ~ 4200MHz
●	Stop Band Attenuation	≥50dB
●	Pass Band Frequency	DC ~ 3030MHz , 4470 ~ 8000MHz
●	Pass Band Insertion Loss	≤1.0dB
●	Pass Band VSWR	≤1.7:1 (Typical: ≤1.5:1)
●	Impedance	50 Ohms
●	Power Handling	5.0W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
