Serial

Parameters

1

Stop Band Center Frequency

780.5MHz

2

Stop Band Frequency

758～803MHz

3

Stop Band Attenuation

≥40dB

4

Pass Band Frequency

DC～733MHz & 828～2190MHz

5

Pass Band Insertion Loss

≤0.75dB / ≤1.0dB @ Corners

6

Pass Band VSWR

≤1.5:1 @ DC～733MHz & 828～2000MHz

≤1.7:1 @ 2000～2190MHz

7

Impedance

50 ohms

8

Power Handling

≤5W

9

Connectors

SMA-Female

10

Surface Finish

Black Paint

11

Temperature Range

-20℃～+60℃

12

Net Weight

TBD

13

Configuration

As Below (Size Unit: mm)
