S/N

Item

Parameters

1

Center Frequency(F0)

1500MHz

2

Pass Band Bandwidth

10MHz (1495 ~ 1505MHz)

3

Pass Band Insertion Loss

≤3.5dB

4

Pass Band Ripple

≤0.3dB

5

Pass Band VSWR

≤1.4:1

6

Stop Band Rejection

≥25dB @ DC ~ 1400MHz

≥25dB @ 1600 ~ 3000MHz

7

Impedance

50 Ohms

8

Power Handling

1.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
