Band Pass Filter

  • 9200-9400MHz Cavity Band Pass Filter
9200-9400MHz Cavity Band Pass Filter

9200-9400MHz Cavity Band Pass Filter

  • P/N:HXLBQ-DTA584
  • Pass Band Frequency:9200-9400MHz
  • Stop Band Attenuation:≥55dB
  • Connectors:N-Female
  • Product description:
  • PDF technical index download

Cavity Band Pass Filter
Technical Data Sheet

S/N

Item

Parameters

1

Center Frequency(F0)

9300MHz

2

Pass Band Frequency

9200 ~ 9400MHz

3

Pass Band Insertion Loss

≤0.8dB

4

Pass Band Ripple

≤0.3dB

5

Pass Band VSWR

≤1.2:1

6

Stop Band Rejection

≥55dB @ DC ~ 8765MHz

≥55dB @ 9835 ~ 12000MHz

7

Impedance

50 Ohms

8

Power Handling

50W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
