Serial

Parameters

1

Center Frequency (F0)

3500MHz

2

Pass Band Frequency

3400～3600MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Attenuation

≥50dB @ F0±300MHz

(DC～3200MHz、3800～6000MHz)

6

Impedance

50 ohms

7

Surface Finish

Black Paint

8

Power Handling

≤10W

9

Connectors

N-Female

10

Net Weight

0.115 KG

11

Configuration

As Below (Size Unit: mm)
