S/N

Item

Parameters

1

Center Frequency(F0)

3500MHz

2

Pass Band Frequency

3398 ~ 3602MHz

3

Pass Band Insertion Loss

≤1.8dB

4

Pass Band Ripple

≤0.9dB @ 3400 ~ 3600MHz

5

Pass Band Return Loss

≥18dB

6

Stop Band Rejection

≥40dB @ DC ~ 3352MHz

≥20dB @ 3352 ~ 3362MHz

≥20dB @ 3638 ~ 3648MHz

≥40dB @ 3648 ~ 3698MHz

≥70dB @ 3698 ~ 4400MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

13

Dimensions

74*56*21mm

14

Net weight

TBD
