S/N

Item

Parameters

1

Stop Band Frequency

758 ~ 788MHz

2

Stop Band Attenuation

≥40dB

3

Pass Band Frequency

DC ~ 740MHz , 806 ~ 2200MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.5:1

6

Impedance

50 Ohms

7

Power Handling

10W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

265*88*28mm
