S/N

Item

Parameters

1

Center Frequency(F0)

3320MHz

2

Pass Band Frequency

3315 ~ 3325MHz

3

Pass Band Insertion Loss

≤0.6dB

4

Pass Band Ripple

≤0.15dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥30dB @ DC ~ 3235MHz

≥30dB @ 3405 ~ 7000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
