S/N

Item

Parameters

1

Center Frequency(F0)

9300MHz

2

Pass Band Frequency

9200 ~ 9400MHz

3

Pass Band Insertion Loss

≤0.8dB

4

Pass Band Ripple

≤0.3dB

5

Pass Band VSWR

≤1.2:1

6

Stop Band Rejection

≥55dB @ DC ~ 8765MHz

≥55dB @ 9835 ~ 12000MHz

7

Impedance

50 Ohms

8

Power Handling

50W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
