S/N

Item

Parameters

1

Center Frequency(F0)

8000MHz

2

Pass Band Frequency

7500 ~ 8500MHz

3

Pass Band Insertion Loss

≤0.9dB

4

Pass Band Ripple

≤0.25dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 7000MHz

≥80dB @ 9000 ~ 22000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
