S/N

Item

Parameters

1

Stop Band Frequency

4400 ~ 5000MHz

2

Stop Band Attenuation

≥50dB

3

Pass Band Frequency

DC ~ 4250MHz , 5150 ~ 10000MHz

4

Pass Band Insertion Loss

≤2.5dB

5

Pass Band VSWR

≤1.7:1

6

Impedance

50 Ohms

7

Power Handling

5W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: Stainless Steel

Other screw: Stainless Steel

12

Dimensions

141*26*16mm

13

Net weight

TBD
