Serial

Parameters

1

Center Frequency (F0)

39.5GHz

2

Pass Band Frequency

37～42GHz

3

Pass Band Insertion Loss

≤1.8dB

4

Pass Band VSWR

≤1.5:1

5

Stop Band Rejection

≥60dB @ DC～35.4GHz

≥55dB @ 43.6～50GHz

6

Impedance

50 ohms

7

Power Handling

≤5W

8

Connectors

Input: 2.92mm(K)-Male

Output: 2.92mm(K)- Female

9

Surface Finish

Black Paint

10

Temperature Range

-30℃～+70℃

11

Net Weight

0.05 KG

12

Configuration

As Below (Size Unit: mm)
