Serial

Parameters

1

Stop Band Frequency

2620～2690MHz

2

Stop Band Attenuation

≥50dB

3

Pass Band Frequency

DC～2595MHz & 2715～6000MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.5:1

6

Impedance

50 ohms

7

Surface Finish

Black Paint

8

Power Handling

≤50W

9

Connectors

SMA-Female

10

Configuration

As Below (Size Unit: mm)
