Technical Data Sheet
●	Stop Band Frequency	863 ~ 928MHz
●	Stop Band Attenuation	≥50dB
●	Pass Band Frequency	DC ~ 833MHz , 958 ~ 2700MHz
●	Pass Band Insertion Loss	≤1.5dB (at the corner: 2.0dB Max.)
●	Pass Band VSWR	≤1.5:1
●	Impedance	50 Ohms
●	Power	10W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-20℃ ~ +60℃
Test Curve
