Serial

Parameters

1

Stop Band Frequency

5470～5725MHz

2

Stop Band Attenuation

≥50dB

3

Pass Band Frequency

DC～5320MHz & 5875～10000MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.8:1

6

Impedance

50 ohms

7

Surface Finish

Black Paint

8

Power Handling

≤10W

9

Connectors

SMA-Female (Flange Structure)

[Material: Stainless Steel]

10

Temperature Range

-40℃～+60℃

11

Net Weight

0.09 KG

12

Configuration

As Below (Size Unit: mm)
