S/N

Item

Parameters

1

Stop Band Frequency

4990 ~ 5010MHz

2

Stop Band Attenuation

≥40dB

3

Pass Band Frequency

DC ~ 4950MHz , 5050 ~ 12000MHz

4

Pass Band Insertion Loss

≤2.5dB

5

Pass Band VSWR

≤1.7:1

6

Impedance

50 Ohms

7

Power

30W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-10℃ ~ +50℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: Stainless Steel

Other screw: Stainless Steel

12

Dimensions

141*28*16mm

13

Net weight

TBD
