Serial

Parameters

1

Stop Band Frequency

3300～3800MHz

2

Stop Band Rejection

≥45dB

3

Pass Band Frequency

0～3180MHz & 3920～8000MHz

4

Pass Band Insertion Loss

≤2.5dB

5

Pass Band VSWR

≤1.7:1

6

Impedance

50 ohms

7

Power Handling

≤10W CW

8

Connectors

SMA-Female

9

Surface Finish

Black Paint

10

Temperature Range

-20℃～+60℃

11

Net Weight

TBD

12

Configuration

As Below (Size Unit: mm)
