Technical Data Sheet
●	Center Frequency(F0)	20MHz
●	Pass Band Frequency	18 ~ 22MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.5dB
●	Pass Band VSWR	≤1.4:1
●	Pass Band Group Delay Variation	≤50ns
●	Stop Band Rejection	≥30dB @ DC ~ 15MHz	≥30dB @ 30 ~ 300MHz
●	Impedance	50 Ohms
●	Power Handling	1.0W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
