S/N

Item

Parameters

1

Center Frequency(F0)

15.7GHz

2

Pass Band Frequency

14.9 ~ 16.5GHz

3

Pass Band Insertion Loss

≤0.7dB

4

Pass Band Ripple

≤0.27dB

5

Pass Band Return Loss

≥23dB

6

Stop Band Rejection

≥80dB @ DC ~ 13.75GHz

≥80dB @ 17.55 ~ 33GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
