S/N

Item

Parameters

1

Center Frequency(F0)

1575MHz

2

Pass Band Frequency

1570 ~ 1580MHz

3

Pass Band Insertion Loss

≤1.7dB (Typical: ≤1.5dB)

4

Pass Band Ripple

≤0.3dB

5

Pass Band Return Loss

≥23dB

6

Stop Band Rejection

≥50dB @ DC ~ 1550MHz

≥50dB @ 1600 ~ 4000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Temperature Range

-10℃ ~ +50℃
