Technical Data Sheet
●	Center Frequency(F0)	1800MHz
●	Pass Band Frequency	1750 ~ 1850MHz
●	Pass Band Insertion Loss	≤1.3dB
●	Pass Band Ripple	≤0.6dB
●	Pass Band Return Loss	≥23dB
●	Stop Band Rejection	≥60dB @ DC ~ 1650MHz	≥60dB @ 1950 ~ 5000MHz
●	Impedance	50 Ohms
●	Power	50W Max.
●	Connectors	N-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
