S/N

Item

Parameters

1

Center Frequency(F0)

10000MHz

2

3dB Bandwidth

20MHz Max. (9990 ~ 10010MHz Max.)

3

Insertion Loss @ F0

≤2.0dB @ 10000MHz

4

Return Loss @ F0

≥18dB @ 10000MHz

5

Stop Band Rejection

≥40dB @ F0±70MHz (DC ~ 9930MHz , 10070 ~ 13000MHz)

6

Impedance

50 Ohms

7

Power

5.0W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black
