S/N

Item

Parameters

1

Center Frequency(F0)

15.55GHz

2

Pass Band Frequency

14.8 ~ 16.3GHz

3

Pass Band Insertion Loss

≤1.7dB

4

Pass Band Ripple

≤0.8dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 14.15GHz

≥50dB @ 14.15 ~ 14.4GHz

≥50dB @ 16.7 ~ 16.95GHz

≥80dB @ 16.95 ~ 27GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
