S/N

Item

Parameters

1

Center Frequency(F0)

100MHz

2

1.0dB Pass Band Bandwidth

10MHz (95 ~ 105MHz)

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.5:1

5

Stop Band Attenuation

≥60dB @ DC ~ 60MHz

≥60dB @ 145 ~ 300MHz

6

Impedance

50 Ohms

7

Power Handling

1.0W Max.

8

Connectors

ø0.5*10mm PIN

9

Surface Finish

The Original Silver Color

10

Temperature Range

-30℃ ~ +70℃
