S/N

Item

Parameters

1

Center Frequency(F0)

4000MHz

2

Pass Band Frequency

3800 ~ 4200MHz

3

Pass Band Insertion Loss

≤1.8dB

4

Pass Band Ripple

≤0.9dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥70dB @ DC ~ 3600MHz

≥70dB @ 4400 ~ 8200MHz

7

Impedance

50 Ohms

8

Power

100W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
