S/N

Item

Parameters

1

Center Frequency(F0)

1750MHz

2

Pass Band Frequency

1745 ~ 1755MHz

3

Pass Band Insertion Loss

≤1.8dB

4

Pass Band Ripple

≤0.4dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥40dB @ DC ~ 1735MHz

≥40dB @ 1765 ~ 3500MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
