S/N

Item

Parameters

1

Center Frequency(F0)

4190MHz

2

Pass Band Frequency

4140 ~ 4240MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.4dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥50dB @ DC ~ 4090MHz

≥50dB @ 4290 ~ 8000MHz

7

Impedance

50 Ohms

8

Power

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
