S/N

Item

Parameters

1

Center Frequency(F0)

3.0GHz

2

Pass Band Frequency

2.0 ~ 4.0GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band VSWR

≤1.7:1

6

Stop Band Attenuation

≥60dB @ DC ~ 1.65GHz

≥60dB @ 4.35 ~ 6.2GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
