Serial

Parameters

1

Stop Band Frequency

920～928MHz

2

Stop Band Attenuation

≥40dB

3

Pass Band Frequency

DC～911MHz & 937～2500MHz

4

Pass Band Insertion Loss

≤1.0dB @ DC～901MHz & 947～2500MHz

≤2.5dB @ 901～911MHz & 937～947MHz

5

Pass Band VSWR

≤1.5:1

6

Impedance

50 ohms

7

Power Handling

≤20W

8

Connectors

SMA-Female

9

Surface Finish

Black Paint

10

Net Weight

0.715 KG

11

Configuration

As Below (Size Unit: mm)
