Serial

Parameters

1

中心频率(Center Frequency)[F0]

2250MHz

2

通带频率(Pass Band Frequency)

2190～2310MHz

3

插入损耗(Insertion Loss)

≤3.5dB

4

带内波动(Ripple in Band)

≤2.0dB

5

驻波比(VSWR)

≤1.3:1

6

带外抑制(Rejection)

≥70dB @ Fc±70MHz

(DC～2120MHz、2380～5000MHz)

7

阻抗(Impedance)

50 ohms

8

功率(Power)

≤10W

9

表面处理(Surface Finish)

黑色烤漆 (Black Paint)

10

接口形式(Connectors)

SMA-Female

11

净重(Net Weight)

TBD

12

外形结构图(Configuration)

As Below (Size Unit: mm)
