Serial

Parameters

1

Stop Band Frequency

824～894MHz

2

Stop Band Attenuation

≥50dB

3

Pass Band Frequency

DC～774MHz & 944～2400MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.7:1

6

Impedance

50 ohms

7

Power Handling

≤20W

8

Connectors

SMA-Female

9

Surface Finish

Black Paint

10

Net Weight

TBD

11

Configuration

As Below (Size Unit: mm)
