S/N

Item

Parameters

1

Stop Band Frequency

617 ~ 652MHz

2

Stop Band Attenuation

≥50dB

3

Pass Band Frequency

DC ~ 587MHz , 707 ~ 1800MHz

4

Pass Band Insertion Loss

≤1.0dB (at the corner: 1.5dB Max.)

5

Pass Band VSWR

≤1.5:1 @ 330 ~ 587MHz , 707 ~ 1800MHz

≤1.7:1 @ DC ~ 330MHz

6

Impedance

50 Ohms

7

Power Handling

10W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-20℃ ~ +60℃
