Serial

Parameters

1

Stop Band Frequency

699～716MHz

2

Stop Band Attenuation

≥40dB

3

Pass Band Frequency

DC～679MHz & 736～2100MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.5:1 @ DC～679MHz & 736～1900MHz

≤1.7:1 @ 1900～2100MHz

6

Impedance

50 ohms

7

Surface Finish

Black Paint

8

Power Handling

≤50W

9

Connectors

SMA-Female

10

Configuration

As Below (Size Unit: mm)
