S/N

Item

Parameters

1

Pass Band Frequency

DC ~ 300MHz

2

Pass Band Insertion Loss

≤2.5dB

3

Pass Band VSWR

≤1.5:1

4

Stop Band Rejection

≥40dB @ 400 ~ 1000MHz

5

Impedance

50 Ohms

6

Power Handling

1.0W Max.

7

Connectors

SMA-Male / SMA-Female

8

Surface Finish

Painted Black

9

Temperature Range

-30℃ ~ +70℃

10

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

11

Dimensions

30*18*13mm
