S/N

Item

Parameters

1

Center Frequency(F0)

1413.5MHz

2

Pass Band Frequency

1400 ~ 1427MHz

3

Pass Band Insertion Loss

≤1.7dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band Return Loss

≥23dB

6

Stop Band Rejection

≥50dB @ DC ~ 1375MHz

≥50dB @ 1452 ~ 3500MHz

7

Impedance

50 Ohms

8

Power Handling

200W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
