S/N

Item

Parameters

1

Center Frequency(F0)

1581.5MHz

2

Pass Band Frequency

1557 ~ 1606MHz

3

Pass Band Insertion Loss

≤1.2dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 1507MHz

≥80dB @ 1656 ~ 4000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-20℃ ~ +60℃
