1065-1115MHz腔体带通滤波器

S/N

Item

Parameters

1

Center Frequency(F0)

1090MHz

2

Pass Band Frequency

1065 ~ 1115MHz

3

Pass Band Insertion Loss

≤1.7dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Attenuation

≥40dB @ DC ~ 1035MHz

≥40dB @ 1145 ~ 3500MHz

7

Impedance

50 Ohms

8

Power Handling

30W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
