S/N

Item

Parameters

1

Center Frequency(F0)

11GHz

2

Pass Band Frequency

10 ~ 12GHz

3

Pass Band Insertion Loss

≤0.8dB

4

Pass Band Ripple

≤0.28dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 8.9GHz

≥40dB @ 8.9 ~ 9.5GHz

≥40dB @ 12.45 ~ 12.95GHz

≥80dB @ 12.95 ~ 23GHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
