S/N

Item

Parameters

1

Center Frequency(F0)

17.25GHz

2

Pass Band Frequency

16.5 ~ 18GHz

3

Pass Band Insertion Loss

≤1.7dB

4

Pass Band Ripple

≤0.8dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 15.85GHz

≥50dB @ 15.85 ~ 16.1GHz

≥50dB @ 18.4 ~ 18.65GHz

≥80dB @ 18.65 ~ 30GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
