S/N

Item

Parameters

1

Center Frequency(F0)

8.75GHz

2

Pass Band Frequency

8.0 ~ 9.5GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 7.35GHz

≥50dB @ 7.35 ~ 7.6GHz

≥50dB @ 9.9 ~ 10.1GHz

≥80dB @ 10.1 ~ 26GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
