S/N

Item

Parameters

1

Center Frequency(F0)

7.05GHz

2

Pass Band Frequency

6.3 ~ 7.8GHz

3

Pass Band Insertion Loss

≤1.2dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 5.55GHz

≥50dB @ 5.55 ~ 5.9GHz

≥50dB @ 8.2 ~ 8.4GHz

≥80dB @ 8.4 ~ 19GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
