S/N

Item

Parameters

1

Center Frequency(F0)

3620.5MHz

2

Pass Band Frequency

3570.5 ~ 3670.5MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Attenuation

≥80dB @ DC ~ 3440.5MHz

≥40dB @ 3440.5 ~ 3520.5MHz

≥40dB @ 3720.5 ~ 3800.5MHz

≥80dB @ 3800.5 ~ 8000MHz

7

Impedance

50 Ohms

8

Power Handling

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
