S/N

Item

Parameters

1

Center Frequency(F0)

3500MHz

2

Pass Band Frequency

3425 ~ 3575MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.7dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥40dB @ DC ~ 3350MHz

≥40dB @ 3650 ~ 7000MHz

7

Impedance

50 Ohms

8

Power

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
