S/N

Item

Parameters

1

Center Frequency(F0)

663MHz

2

Pass Band Frequency

653 ~ 673MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.7dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥40dB @ DC ~ 643MHz

≥40dB @ 683 ~ 1400MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
