S/N

Item

Parameters

1

Center Frequency(F0)

6000MHz

2

3.0dB Bandwidth

20MHz (5990 ~ 6010MHz)

3

Insertion Loss @ F0

≤1.5dB @ 6000MHz

4

VSWR

≤1.4:1 @ 5997 ~ 6003MHz

5

Stop Band Rejection

≥40dB @ DC ~ 5840MHz

≥40dB @ 6160 ~ 10000MHz

6

Impedance

50 Ohms

7

Power

5.0W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

+15℃ ~ +30℃
