S/N

Item

Parameters

1

Center Frequency(F0)

10.9GHz

2

Pass Band Frequency

10.4 ~ 11.4GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥50dB @ DC ~ 9.9GHz

≥50dB @ 11.9 ~ 18GHz

7

Impedance

50 Ohms

8

Power

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
