S/N

Item

Parameters

1

Center Frequency(F0)

718MHz

2

Pass Band Frequency

703 ~ 733MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.4dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥50dB @ DC ~ 678MHz

≥50dB @ 758 ~ 2000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
