S/N

Item

Parameters

1

Center Frequency(F0)

10GHz

2

Pass Band Frequency

8.0 ~ 12GHz

3

Pass Band Insertion Loss

≤0.8dB

4

Pass Band Ripple

≤0.45dB

5

Pass Band Return Loss

≥18dB

6

Stop Band Rejection

≥60dB @ DC ~ 7.1GHz

≥60dB @ 12.7 ~ 22GHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
